Key Features
• 6-Port Gigabit Design – Includes 4 Gigabit PoE ports and 2 Gigabit uplink ports for high-speed network connectivity.
• 30W PoE Output – Delivers up to 30W of power per PoE port for compatible devices.
• 48W Total PoE Budget – Provides sufficient power for multiple PoE-enabled cameras and network devices.
• IEEE PoE Compatibility – Supports IEEE 802.3af and IEEE 802.3at PoE standards.
• Gigabit Data Transfer – Offers 1000 Mbps transmission with a maximum cable distance of 100 meters.
• High Switching Performance – 12 Gbps switching capacity ensures smooth and stable network traffic.
• Reliable Protection – Built-in 2KV lightning protection and ESD protection enhance device safety.
• LED Status Indicators – Easy monitoring of power, link status, and data transmission through LED indicators.
• Integrated Power Supply – Operates with 110–264V AC input and consumes less than 5W (excluding PoE load).
• Compact & Durable Design – Suitable for homes, offices, retail stores, and professional CCTV installations.
Technical Specifications
Model: CP-DNW-GPU4G2-48
• Ports: 6 (4 Gigabit PoE + 2 Gigabit Uplink)
• PoE Standard: IEEE 802.3af / IEEE 802.3at
• PoE Output: Up to 30W per Port
• PoE Power Budget: 48W
• Switch Capacity: 12 Gbps (Full Duplex)
• Packet Forwarding Rate: 1.488 Mpps per Port
• Transmission Distance: Up to 100 m
• MAC Address Table: 2K
• Power Supply: Built-in, 110–264V AC, 50/60Hz
• Power Consumption: <5W (without PoE load)
• Lightning Protection: 2KV (Common & Differential Mode)
• ESD Protection: 1.5KV Air / 1.5KV Contact Discharge
• Operating Temperature: -10°C to +50°C
• Storage Temperature: -40°C to +70°C
• Humidity: 10%–95% (Non-condensing)
• Dimensions: 202 × 140 × 45 mm
